The Studer S36 is a CNC external cylindrical production grinder engineered for high-volume OD grinding of shaft-type and cylindrical workpieces. Built on a Granitan S103 mineral-cast base and equipped with a powerful grinding spindle and modern CNC control, the S36 delivers excellent dimensional stability, surface finish and repeatable grinding performance.
With a center height of 225 mm and 650 mm between centers, the Studer S36 is ideal for automotive components, hydraulic shafts and other cylindrical parts that require stable, efficient grinding over long production runs. A large 610 mm grinding wheel, fixed wheelhead and optimized coolant delivery support aggressive stock removal while maintaining tight tolerances.
Depending on configuration and year, used Studer S36 machines may be equipped with Fanuc-based CNC controls or Studer C.O.R.E. platforms, and are often prepared for automation interfaces, in-process gauging and digital monitoring options.
| Specification | Details |
|---|---|
| Model | Studer S36 |
| Type | CNC external cylindrical production grinder |
| Center Height | 225 mm |
| Distance Between Centers | 650 mm |
| Max Workpiece Length | Approx. 800 mm including clamping |
| Max Workpiece Diameter | Up to about 449 mm |
| Max Workpiece Weight Between Centers | Up to about 150 kg |
| X-Axis Travel | 370 mm |
| Z-Axis Travel | 800 mm |
| Grinding Wheel Diameter | 610 mm |
| Grinding Wheel Width | Typically 80–125 mm, 125 mm max |
| Spindle Power | Up to 15 kW grinding spindle motor (depending on wheel configuration) |
| Max Wheel Speed | Approx. 1,500 rpm (≈48 m/s with 610 mm wheel) |
| Control System | Fanuc 16i-T or Studer C.O.R.E.-based CNC (varies by machine year) |
| Machine Base | Granitan S103 mineral-cast base |
| Wheelhead Configuration | Fixed external wheelhead, wheel on right, settable at 0° / 15° / 30° |
| Dressing | Table with double T-slot prepared for automatic dressing units |
| Approximate Machine Weight | Approx. 4,500 kg (varies with equipment) |
| Notes | Specifications may vary by year and configuration. Confirm exact specs from the specific machine nameplate and documentation. |
Sell a Studer S36 Grinder
Studer Grinder Models
Studer S36 CNC Grinder FAQ
The Studer S36 is a CNC external cylindrical production grinder designed for high-volume OD grinding of shafts and cylindrical components. It combines a Granitan S103 base, large grinding wheel and modern CNC control to deliver stable, repeatable grinding performance in demanding production environments.
A typical Studer S36 offers about 225 mm center height and 650 mm distance between centers, allowing workpieces up to roughly 800 mm long (including clamping), with diameters up to around 449 mm and weights up to about 150 kg between centers. Actual capacities depend on the specific machine configuration.
Common features include a fixed external wheelhead with a 610 mm grinding wheel, linear X and Z axes with C-axis workhead, mineral-cast Granitan S103 base, integrated table T-slots for dressing units, optimized coolant delivery and modern CNC control (Fanuc or Studer C.O.R.E.). Many machines are prepared for automation, in-process gauging and digital monitoring solutions.
Yes. If you have a Studer S36 or other Studer CNC cylindrical grinder to sell, use the Free Machine Appraisal form on this page or our Sell Machinery form to request a no-obligation appraisal.
